1. Emerson Quality Flow Meter Specifications

The specifications of Emerson quality flow meters vary depending on the model, but their general performance and some typical model configurations can provide you with clear references. 1. General specification measurement accuracy: The accuracy of liquid measurement is between 0.1% and 0.05%, and the repeatability is between 0.05% and 0.025%; The gas measurement accuracy ranges from 0.25% to 0.35%, with a repeatability of 0.20%; The accuracy of density measurement for crack bridge clearance is 0.0005 to 0.0002 g/cc, and the repeatability is 0.00025 to 0.0001 g/cc. Caliber range: covering a wide range of sizes from 1/12 inch (DN2) to 12 inches (DN300). Pressure range: The selected rated pressure can reach 414 barg (6000 PSI). Temperature range: capable of stable operation in harsh environments ranging from -240 ° C to 350 ° C (-400 ° F to 662 ° F). Electronic components: Provides rich I/O options, including mA, frequency, discrete signals, as well as multiple communication protocols such as HART, Modbus, Ethernet/IP, PROFINET, FOUNDATION fieldbus, etc.

2. Specific specifications for some models CMFS sensor series (taking CMFS010M323M6BAMCZZ as an example) Sensor size: 1/10 inch (DN2). Basic model material: 316L stainless steel. Process connection: # 4 VCO 316/316L Swagelok compatible connector, equipped with 1/4 inch NPT internal thread adapter. Shell and hygiene options: Made of 316L stainless steel shell. Electronic interface: Configure MVDSolo; Polyester paint coated aluminum integrated enhanced core processor (for OEM); When ordering instruments with certification codes C, A, Z, and damping I, MVD Direct Connect intrinsic safety barriers will be provided;

This configuration is not applicable for certification code U. Wiring conduit connection: 1/2 inch NPT - no sealed joint. Certification: Obtained CSA (US and Canada) certification, applicable to Class I, Zone 1, Groups A, B, C, and D (for CMFS type); C and D groups (for CMF type). Language: Provide Chinese installation manual. Calibration: The factory calibration is for a mass flow rate of 0.10% and a density of 0.002 g/cm ³ (2.0 kg/m ³). Measurement application software: No measurement application software available. Factory options: Standard products. F200S model accuracy level: up to 0.005. Applicable media: Widely applicable to various media such as gas, liquid, gas-solid two-phase flow, liquid-solid two-phase flow, hot water, cold water, sewage, etc. Style: Electronic with digital display. Converter form: integrated. Range ratio: 20:1. Explosion proof mark: with explosion-proof certification.

2. How to select Emerson flow meters based on pipe diameter

Emerson flow meters are mainly selected based on the type of flow meter and the actual flow range. The core is to match the pipe diameter with the flow range to avoid a decrease in measurement accuracy or equipment damage caused by improper pipe diameter.

. 1. The range of pipe diameters and the type of flow meter are compatible with Emersons mainstream flow meters. The range of pipe diameters is different. The Coriolis flow meter is suitable for small pipe diameters, usually DN6-DN200 (1/4 inch -8 inches). Based on the principle of Coriolis force, it has high measurement accuracy for fluid density and mass flow, and is commonly used for small flow additive transportation in the chemical industry. Electromagnetic flowmeter: suitable for a wide range o
