The working principle of electromagnetic flowmeter is based on Faradays law of electromagnetic induction. The sensor part consists of a coil, electrodes, and insulation lining. During measurement, the excitation coil in the sensor is energized to generate a magnetic field. When the conductive fluid passes through the magnetic field, a small induced electromotive force is generated due to the cutting force of the magnetic field lines. The electrodes collect these small induced electromotive forces and transmit them to the converter part of the instrument for amplification, correction, and other operations. Then, they are converted into corresponding flow data through formulas, and finally displayed on the instrument or output to the upper computer system. When a conductive fluid flows through a magnetic field perpendicular to the flow direction, the conductive liquid induces an induced voltage E proportional to the average flow velocity. The induced voltage is detected by two electrodes in direct contact with the fluid, amplified, filtered, and shaped by a converter, and sent to the MCU for display and output control of instantaneous and cumulative flow rates. E=KBVD formula: E - Induced voltage K - Instrument constant B - Magnetic induction intensity V - Measurement of average flow velocity inside the pipe surface D - Flow meter diameter product structure diagram. A good electromagnetic flowmeter has high measurement accuracy and stable product performance. Before the electromagnetic flowmeter is bright, its accuracy is generally at 0.3 or 0.5 levels, while some small-diameter products can achieve 0.2 levels. Due to the particularity of its principle of measuring destructive width, it is necessary to measure the medi
(1) There are no obstructing flow components or pressure loss inside the measuring tube, and the requirements for the straight pipe section are relatively low;
(2) High measurement accuracy, strong stability, and strong resistance to vibration interference; (3) Measurement is not affected by changes in fluid density, viscosity, temperature, pressure, and conductivity;
(4) With multiple electrode and lining options, it has strong resistance to medium corrosion.
2. How to install electromagnetic flowmeter: Electromagnetic flowmeter wiring diagram
3. Share the wiring method of the two-wire system for vortex flowmeter?
For the two-wire wiring method of the vortex flowmeter, please refer to the attached diagram. When you open the junction box, you can see a row of wiring terminals on the green circuit board. The first group is connected to the positive+24V power line, and the second group is connected to the current output signal accompanying wire. The two-wire wiring method here is 24V+and current I+. If this is a combination wiring, that is, the wiring method for the 4-20mA output of the two-wire system, be sure to pay special attention when wiring and do not connect it incorrectly.
