How much length of straight pipe should be left before and after the installation of the flowmeter? Do you have any specific requirements!

For metal tube rotor flow meters, the standard of the Ministry of Machinery stipulates that the front straight pipe section should be at least 10 times the diameter of the flow meter, starting from the upstream flange end face of the flow meter. The rear straight pipe section should be at least 5 times the diameter of the flow meter, starting from the downstream flange end face of the flow meter.. DN refers to the diameter of the flow meter. The standard of the mechanical department does not specify the length of the straight pipe section before and after the glass rotor flowmeter. However, it is stipulated that if a flow regulating valve is to be installed, it must be installed at 5-10 times the DN downstream of the flowmeter, starting from the flange end face downstream of the flowmeter. DN refers to the diameter of the flow meter. Additional information: When installing a traffic meter, in order to achieve the same accuracy as real flow verification, it is necessary to meet the specified flow conditions. At present, except for a few types such as volumetric and Coriolis mass flow meters, there are specific requirements for the length of the front and rear straight pipe sections. A velocity flowmeter is a flowmeter based on the principle of directly measuring the flow velocity of a fully enclosed pipeline. Although there are various types of flow meters, their measurement principles are the same. The accuracy of the measured flow velocity is not only related to the accuracy of the flowmeter itself, but also to its installation position. The idea

2. The terms "flow meter front 5, back 3" or "front 10, back 5" mainly depend on the measurement requirements.

.

1、 Specifically, the top 5 and bottom 3 indicate that there needs to be a straight pipe section with a length of 5 times the pipe diameter in front of the flowmeter, while there needs to be a straight pipe section with a length of 3 times the pipe diameter behind the flowmeter. The top ten and bottom five indicate that there needs to be a straight pipe section with a length of 10 times the pipe diameter in front of the flowmeter, and a straight pipe section with a length of 5 times the pipe diameter behind the flowmeter.

2、 The installation requirements of front 5 and back 3, front 10 and back 5 of the flowmeter are both designed to ensure that the flow state of the fluid in the flowmeter is stable and stable, thereby improving the accuracy of measurement. The requirements for the top 5 and bottom 3 are relatively low, while the top 10 and bottom 5 are more stringent standards. In practical applications, appropriate installation requirements should be selected based on factors such as specific fluid conditions, pipeline diameter, and flow meter type.
