What does LFX mean in the specifications and models of flow meters? LFX in the specifications and models of flow meters represents a rotary turbine steam flow meter. Here are some key points about the LFX rotary steam flowmeter: Type identification: LFX is the prefix used by a specific manufacturer to identify its rotary steam flowmeter model. This identifier helps users quickly identify the category and purpose of the product. Working principle: The rotor type steam flowmeter determines the flow rate by measuring the rotational speed of the rotor when the fluid flows through it. When steam flows through the flowmeter, the rotor rotates due to the impact force of the steam, and the rotational speed is proportional to the steam flow rate. Applicable scenarios: This type of flowmeter is usually used to measure the flow rate of high-temperature and high-pressure fluids such as steam, and is widely used in industrial production and energy metering fields. Performance characteristics: LFX rotary wing steam flowmeter has the characteristics of accurate measurement, stable and reliable, and easy use and maintenance. At the same time, it can adapt to various working conditions and meet the measurement needs of different users. In summary, LFX, as a part of the flowmeter specification model, represents a specific type of product, the rotary wing steam flowmeter.

2. Flow range of steam vortex flowmeter

The flow range of steam vortex flowmeter varies depending on its model and diameter.

. The diameter (DN) represents the diameter of the pipeline, while the flow range represents the flow value that the flowmeter can measure. The model OW-LU-25 is suitable for DN25 pipelines, with a flow range of liquid 1-10 m ³ Steam flowmeter model

/h and gas 25-60 m ³/h. For steam flow, it is recommended to refer to the instruction manual. For large pipelines above DN300, it is recommended to use an inserted vortex flowmeter. The model OW-LU-32 is suitable for DN32 pipelines, with a flow range of 1.5-18 m ³/h for liquids and 15-150 m ³/h for gases. The model OW-LU-40 is suitable for DN40 pipelines, with a flow range of 2.2-27 m ³/h for liquids and 22.6-150 m ³/h for gases. The model OW-LU-50 is suitable for DN50 pipelines, with a flow range of liquid 4~55 m ³/h and gas 35~350 m ³/h. The model OW-LU-80 is suitable for DN80 pipelines, with a flow range of 9-135 m ³/h for liquid differential and 90-900 m ³/h for gas. The model OW-LU-100 is suitable for DN100 pipelines, with a flow range of 14-200 m ³/h for liquids and 140-1400 m ³/h for gases. The model OW-LU-150 is suitable for DN150 pipelines, with a flow range of 32-480 m ³/h for liquids and 300-3000 m ³/h for gases. The model OW-LU-200 is suitable for DN200 pipelines, with a flow range of 56~800 m ³/h for liquids and 550~5500 m ³/h for gases. Based on the above information, you can choose a suitable steam vortex flowmeter according to your pipeline diameter and understand the flow range it can measure. The steam vortex flowmeter is mainly used for measuring the flow rate of steam medium fluid in industrial pipelines. The characteristics of steam vortex flowmeter are small pressure loss, large range, high accuracy, and it is almost not affected by fluid density, pressure, temperature, viscosity and other parameters when measuring the volumetric flow rate under working conditions.
